LED Power Repeater

MOQ ：1 piece

Lead Time ：1 Days

Inquiry Start Order

Seller Support : Trade Authenticity Guaranteed & Accepting

Payment : T/T,Western Union,Money Gram

Departure Port : Zhuhai, China

Product details

Supply Ability

Supply Ability：10000 piecesWarranty(Year)：2 Year

Packaging & Delivery

Length：12 cmWidth：4 cm
Height：4 cm
Packaging：1 piece

Product Specifications

Product Description

LED Power Repeater

LED power repeater is suitable for all of our single color & RGB controllers to expand power output, it supports PWM control and can connect one to three times more LEDs by adding one more power repeater, and unlimited power repeaters can be connected together theoretically.

The constant voltage power repeater and constant current power repeaters can be connected together, which is convenient for controlling LEDs with different voltage and power.

BC-960Constant Voltage Power Repeater

Product Parameter

Model	BC-960	BC-960-8A	BC-960-10A
Input voltage	DC12V-DC24V	DC12V-DC24V	DC12V-DC24V
Max load current	6A/CH*3	8A/CH×3	10A/CH×1
Max output power	220W(12V)450W(24V)	290W(12V)580W(24V)	120W(12V)240W(24V)
Output signal	CV PWM	CV PWM	CV PWM
Product Dimension	L125xW45xH36(mm)	L165xW56xH36(mm)	L125xW45xH36(mm)
Weight (G.W)	100g	130g	100g

Model	BC-990-350	BC-990-700	BC-990-1050
Input voltage	DC12V-DC48V	DC12V-DC48V	DC12V-DC48V
Max load current	350MA/CH*3	700MA/CH*3	1050MA/CH×3
Driving LEDs	1-12pcs 1W LEDs	1-12pcs 3W LEDs	1-12pcs 5W LEDs
Output signal	CC PWM	CC PWM	CC PWM
Product Dimension	L125xW45xH36(mm)	L125xW45xH36(mm)	L165xW56xH36(mm)
Weight (G.W)	100g	100g	130g
